Quantity:1 piece 188 series collector
Dimensions: 1930 x 930 x 100 mm
Weight: 33.5 kg
Absorber Plate: Copper
Glazing: Solar or Normal glass
Insulation: Glasswool or Polyurethane
Sealantı: EPDM
Case: Aluminium
Moisture Control System:
Connection: ¾".............. . . . .......

System: Closed Loop Thermosiphon
Dimensions:
1200 x Ø500 mm
Weight:
43 kg
Working Pressure:
6 bar
Test Pressure:
12 bar
Insulation:
Glasswool
Outer Coverage:
Galvenized or Stainless Steel
Thermostat Resistor:
2000 W
Corrosion Protection:
Cathodic Protection and Hot Deep Galvanizing



ECONOMY

While the cost of oil, gas, and electricity continiues to rise, energy from the sun is abundant and freely available everywhere. Solareks Solar Hot Water systems are designed to replace costlier forms of energy and quickly recover your initial investment.

USING CAPACITY

-

WIDE USAGE

Because the systems are open loop they may operate in warm geographic areas. Solareks 100 lt open circuit systems are mostly used in areas where there is no risk of mains water freezing and the places where the mains water has no lime.

AESTHETIC

Because the BC Series boilers are pressurized there is no need for a second boiler. Thus a more esthetic view is achieved.

CONFORT

Systems are pressurized and can be directly connected to water mains thus the user has the advantage of having hot water at the pressure of mains water. In order to create a more comfortable use the system is equipped with a thermostat resistor for use in winter. In the winter time when there is no sun light thermostat resistor heats up the water in the boiler to the required temperature.

LONG LASTING LIFE

In open circuit systems the mains water run in the collector thus the circulation of the water is better then the closed loop systems. The pipes of the collector can get blocked by the lime in the water and also in winter the collectors can burst due to freezing water. The system must be used in the warm areas and the places that mains water has a low percantage of lime.







COLLECTOR

Copper collector can be used in the system. Collectors are insulated with glaswool or polyurethane, normal glass or solar glass is used in order to achieve a better light transmittance. The collector is sealt with the UV resistant EPDM rubber and the case is fabricated with aluminium extrusion technique.

BOILER

Boiler is open loop, becouse of that heat exchanger efficiency ratio is % 100. The boilers are coated with 80 - 100 µ zinc in order to achive rustproof and increase the useful life of the boilers. In addition to that BC series boilers are protected with magnesium anodes.

MOUNTING FRAME

The specially designed Solareks installation kit is used in order to mount the collectors and the boiler to the roof. Steel construction fixes the boiler and the collectors on the roof in a very secure and practical way.

INSTALLATION

The systems can be installed in two different ways. The boiler can either be under or on the roof. Regardless of the way of the installation the system is installed in a very secure practical and easy way. Solareks installation kit has an installation compatability to any kind of roof.

SYSTEM EQUIPMENTS

Extra protective elements are used in the systems in order to increase the efficiency of the boiler and protect the boiler and to create a smooth use of hot water.

WARRANTY

2 year
